Fusion Splicer Tumtec
V9
Brand:
TUMTEC
Variant Specifications
Technology:
Product size:
Weight:
More Details:
Warranty: 1 year
Payment Facility: Cash/EMI/PDC
Delivery Lead Time: Same day of payment
Origin: China
18S
16S
16M
18H
83A
83S
V6
4% OFF
Rs 331,858.4100
List: Rs 345,132.7500
Tumtec Fusion Splicer V9
The Tumtec V9+ Fusion Splicer is a high-performance core alignment splicing machine designed for FTTH, backbone, and ISP network deployment. It offers fast splicing, intelligent calibration, and high-capacity battery performance for field operations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | V9 |
| Dimensions |
130 × 170 × 170 mm (without bumper) 140 × 170 × 176 mm (with bumper) |
| Weight | 2.23 kg (with battery) / 1.85 kg (without battery) |
| Fiber Count | Single Fiber |
| Applicable Fibers | SM (G.652/G.657), MM (G.651), DS (G.653), NZDS (G.655) |
| Compatible Cable | 0.25 – 3.0 mm indoor cable |
| Cleave Length |
Diameter: 0.125 – 1 mm Cleave Length: 8 – 16 mm |
| Cladding Diameter | 80 – 150 μm |
| Splicing Modes | 41 preset, max 100 modes |
| Heating Modes | 5 preset (20/30/40/50/60mm), max 100 modes |
| Splice Loss | SM: 0.02 dB, MM: 0.01 dB, DS/NZDS: 0.04 dB, G.657: 0.02 dB |
| Return Loss | ≥ 60 dB |
| Lighting | 3 White LEDs |
| Splicing Time | 6 sec (Quick Mode) |
| Heating Time | 13 sec (quick), 30 sec (typical) |
| Heating Sleeve Length | 20 – 60 mm |
| Storage | 20,000 records & 200 images |
| Tension Test | 1.96 – 2.25 N |
| Display | 5.0” color HD display (90° bi-directional) |
| Magnification | X / Y / XY view, up to 500× |
| Battery | 5200 mAh, approx. 250 splice & heat cycles |
| Power Supply | AC 100–240V / DC 12–15V |
| Operating Condition |
Altitude: 0–5000 m Temperature: -10°C to +50°C Humidity: 0–95% RH Wind: ≤15 m/s |
| Storage Condition | -40°C to +80°C, 0–95% RH |
| Operation Method | Button / Touch Screen |
| Calibration | Automatic arc calibration (pressure & temperature) |
| Electrode Life | 5000 arcs |
| Interface | Mini USB 2.0 |
