D-TECH SFP 10G BIDI Tx1550/Rx 1490nm DDM
80km LC
Brand:
D-TECH
Variant Specifications
Compatible:
Warranty:
Weight:
Country of Origin:
Import Lead Time:
Package:
Warranty:
Weight:
Country of Origin:
More Details:
Import Lead Time:
Package:
Available options
1% OFF
Rs 88,439.6200
List: Rs 89,501.7000
10G SFP+ BIDI Optical Transceiver – 80KM
Single Fiber BIDI • 10G Ethernet • 80KM Long Distance • DDM / DOM Supported
The 10G SFP+ BIDI Optical Transceiver – 80KM is a high-performance single-fiber optical module designed for long-distance 10G Ethernet, ISP backbone, telecom transmission, enterprise fiber, and data center interconnect applications.
Using Bi-Directional (BIDI) transmission technology, this module transmits and receives data over one single mode fiber strand, helping reduce fiber usage and deployment cost. It supports transmission up to 80 km with stable optical performance and low power consumption.
Data Rate
10G
Distance
80KM
Fiber Type
Single Fiber
Connector
LC BIDI
Key Features
✔ Supports 10G High-Speed Optical Transmission
✔ Single-Fiber BIDI Communication Technology
✔ Up to 80 km Transmission Distance
✔ DFB Laser Transmitter with APD Receiver
✔ Digital Diagnostics Monitoring (DDM / DOM)
✔ Low Power Consumption Design
✔ Hot-Pluggable SFP+ Form Factor
✔ Metal Enclosure for Superior EMI Protection
Technical Specifications
| Category | Specification |
|---|---|
| Product Type | SFP+ Optical Transceiver (BIDI) |
| Data Rate | Up to 11.1 Gbps (Typical 10.3125 Gbps) |
| Transmission Distance | Up to 80 km |
| Fiber Type | Single Mode Fiber (9/125 µm) |
| Wavelength | Tx: 1550 nm / Rx: 1490 nm (Reverse option available) |
| Transmitter Type | DFB Laser |
| Receiver Type | APD Photodiode |
| Connector Type | LC BIDI Single Fiber |
| Interface | 2-Wire Serial Interface (I2C, SFF-8472) |
| Digital Diagnostics | DDM / DOM Supported |
| Monitoring Parameters | Temperature, TX Power, RX Power, Voltage, Bias Current |
| Power Supply | +3.3V |
| Power Consumption | ≤ 1.8W |
| EMI Protection | Metal Enclosure |
| Compliance | SFP+ MSA, SFF-8431, SFF-8472 |
| RoHS | RoHS-6 Compliant |
Environmental Specifications
| Operating Temperature (Commercial) | 0°C to +70°C |
| Extended Temperature | -10°C to +80°C |
| Industrial Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% Non-condensing |
Electrical Specifications
| Operating Voltage | 3.135 – 3.465V |
| Typical Voltage | 3.3V |
| Control Voltage (High) | ≥ 2V |
| Control Voltage (Low) | ≤ 0.8V |
Applications
10G Ethernet Networks
ISP Backbone Infrastructure
Telecommunication Systems
Data Center Interconnect
Enterprise Fiber Networks
Long Distance Optical Transmission
DWDM / CWDM Fiber Networks
Note: BIDI optical transceivers must be used in matched wavelength pairs, such as Tx1550/Rx1490 on one side and Tx1490/Rx1550 on the opposite side.
