Description
This rack mount patch panel is used to terminate the providers’ side of an optical fiber cable. It is a steel unit with provision to splice up to external optical fibers to pigtails. The splices and spare optical fibers are stored on the splice trays provided, while the pigtails are located in simplex through connectors at the patch panels in front of the splice trays.It is an ideal solution for rack or cabinet mounting in compact areas. This unit provides excellent fiber patching management.
Features
l Top quality steel with electrostatic painted ensures the strong body and pleasing appearance.
l For standard 19" racks use (other rack width options available on request).
l Fully stable patch panel, no risk of movement.
l Easy operations: Rotate style.
l Cable can be entered from rear; patch cords go out from right front
l Total front access for users.
l Adapter panels are used for quick and easy adapter installations.
l Protected patch panel offers secure environment for adapters, patch cords and pigtails.
l High Density, see the capacity chart below.
l Adoptable adapter types: FC, SC simplex adapters and LC duplex adapters.
Dimensions and Capability
Height | Depth (mm) | Width | Max Capacity (Cores) |
1U | 300 | 19" | FC 24 |
Customized Designable Available Upon Request
Material Quality
Component Name | Thickness (mm) |
Top of box / Bottom of box / Cabinet Post / Cabinet Frame | 1.2 |
Temperature | -5℃ -- 60℃ |
Humidity | 90% at 30℃ |
Air Pressure | 70kPa – 106kPa |
Shipping Information | |
Package Contents |  Patch panel, 3~5 unit
|
Package Dimensions(W*H*D) | It depends on the dimensions of the product |
Material |  Carton box
|
Weight | It depends on the dimensions of the product |
Lead Time | 10-15 working days normally |
