VoIP ONU
HSGQ-X101 SC/UPC
Brand:
HSGQ
Variant Specifications
Compatible:
Warranty:
Weight:
Country of Origin:
Import Lead Time:
Package:
Available options
1% OFF
Rs 4,030.72
List: Rs 4,060.80
HSGQ-X101 EPON/GPON ONU with 1GE + 1POTS
XPON ONU • 1 Gigabit LAN • 1 Voice Port • FTTH / FTTx Broadband Access
The HSGQ-X101 XPON ONU is a compact and high-performance optical network unit designed for FTTH and FTTx broadband deployments. It supports automatic EPON / GPON adaptive mode, 1 Gigabit Ethernet port, and 1 POTS voice port for internet and VoIP services.
With support for TR069 remote management, VLAN, QoS, PPPoE, DHCP, NAT, IPTV, DBA, voice services, and remote software upgrades, the HSGQ-X101 is suitable for telecom operators, ISPs, home users, and office fiber connectivity.
PON Mode
EPON / GPON
LAN Port
1 × GE
Voice Port
1 × POTS
Distance
20KM
Key Features
✔ Supports EPON & GPON Adaptive Mode
✔ 1 × 10/100/1000M RJ45 Gigabit Ethernet Port
✔ 1 × POTS Voice Port for VoIP Services
✔ TR069 Remote Management Supported
✔ VLAN, QoS, DHCP, PPPoE & NAT Support
✔ Dynamic Bandwidth Allocation (DBA)
✔ IPTV & Voice Service Support
✔ Transmission Distance up to 20KM
Technical Specifications
| Category | Specification |
|---|---|
| Model | HSGQ-X101 |
| User Interface | 1 × 10/100/1000M RJ45 + 1 × POTS |
| PON Mode | EPON & GPON Adaptive |
| Optical Connector | SC/UPC or SC/APC |
| Transmission Distance | Up to 20KM |
| GPON Speed | Upstream 1.25Gbps / Downstream 2.5Gbps |
| GPON Optical Power | Tx: 0.5 ~ 5 dBm |
| GPON Receiver Sensitivity | -7 dBm ~ -28 dBm |
| EPON Speed | Upstream 1.25Gbps / Downstream 1.25Gbps |
| EPON Optical Power | Tx: 0 ~ 4 dBm |
| EPON Receiver Sensitivity | ≥ -27 dBm |
| Ethernet Interface | 10/100/1000M Auto Negotiation, Full/Half Duplex |
| POTS Port | 1 × RJ11 Connector |
| POTS Distance | Up to 1KM |
| Power Supply | DC 12V / 1A |
| Power Consumption | < 8W |
| Management | WEB / TELNET / TR069 / OMCI / OAM |
| Dimensions | 132 × 83 × 30 mm |
Environmental Specifications
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Humidity | 5% ~ 95% Non-condensing |
Voice Service Functions
Supports SIP Voice Protocol
Dynamic PPPoE, DHCP & Static IP
High-Speed Modem Dial Access
Call Waiting & Hotline Functions
ITU-T G.711, G.723.1 & G.729
Echo Cancellation Support
Three-party Calling Support
VoIP Voice Communication
Applications
FTTH Broadband Internet
ISP Fiber Network Deployment
VoIP Voice Communication
IPTV Service Distribution
Home Fiber Connectivity
Office Fiber Connectivity
Note:
Please select the correct optical connector type SC/APC or SC/UPC according to your OLT, patch cord, and FTTH network design requirements.
Please select the correct optical connector type SC/APC or SC/UPC according to your OLT, patch cord, and FTTH network design requirements.
Ask a question
Questions & answers
0 question(s)No questions yet. Be the first to ask!
0.0
5★
0
4★
0
3★
0
2★
0
1★
0
Write a review
Sign in to reviewCustomer reviews
No reviews yet. Be the first to review this product.
No videos for this product yet
Once videos are added, you’ll see them here as a gallery.
Related Products
.jpg)
D-TECH Fiber Media converter Single-Mode 10/100Mbps
Rs 3,300
Rs 3,200
Ruijie RG-EW3200GX pro
Rs 22,872
Rs 21,993
HIKVISION POE SWITCH
Contact for price
HDMI Fiber Media Converter
Rs 22,949
Rs 22,676
100G Data Center Switch
Contact for price
D-TECH XFP 10G BIDI Tx1270/Rx 1330nm DDM
